P1.25 GOB LS Series A60PRO Digital Shelf LED Advertising Display Screen Height Size 60mm
| LS Series Item SKU | LS-A60PRO-P1.25 | ||
| LED Configuration | SMD1515 | ||
| Pixel pitch | 1.25mm | ||
| Scan mode | 1/48 scan | ||
| Resolution (Wx H) | 240*48 dots | ||
| Module size (Wx H) | 300mm × 60mm | ||
| Density | 640,000 dots/m² | ||
| Surface Process | GOB | ||
| Brightness | 500cd~800cd/m² | ||
| Viewing Angle | H160°/ V160° | ||
| Frequency | 60frame/s | ||
| Refresh Rate | 3840Hz | ||
| Display Area Dimension (WxH) mm |
300×60 | 600×60 | 900×60 |
| Resolution (Wx H)-dots | 240×48 | 480x48 | 720x48 |
| Module QTY | 1×1 | 2×1 | 3×1 |
| Physical Size(mm) | 305×65×21 | 605×65×21 | 905×65×21 |
| N.W. (KG/PC) | 0.6 | 1.2 | 1.8 |
| Power (max) | 9W/PC | 18W/PC | 27W/PC |
| Power (Avg.) | 5.5W/PC | 8W/PC | 12W/PC |
| Control Modes | Synchronous / Asynchronous | ||
| Working Voltage | Input DC24V | ||
| Working Time | 7×24hrs continuously | ||
| MTBF | ≥10,000Hrs | ||
| LED Lifespan | ≥100,000Hrs | ||
| Working Temperature | -20℃ ~ 60℃ | ||
| Working Humidity | 10％ ～90％RH | ||
| Connection | Seamless splicing, dedicated power connection and universal RJ45 signal communication | ||
| Installation | Supports horizontal screen, vertical screen, counter column, hanging, splicing, embedded and other forms | ||
Buying Tips:
Lead Time: The regular P1.25 modules with wide sizes of 300mm/600mm/900mm has large stocks available at factory. Once your payment is completed and the order is submitted, our assembly time is 3-5 days, included the 72hrs aging test time.
Regarding to customized order, if you need to add different control equipment, the production time for custom orders will be 15-20 days.
Packing Method: We offer eco-friendly, reinforced cardboard boxes and plywood case packaging options. If you prefer a different packaging method, please specify your choice when placing your order. This can also help reduce costs.
Sea Freight Shipping Service: Our default shipping method is sea freight with local truck delivery to your door. The overall transit time may vary depending on the destination country and region. For specific inquiries, please consult our online customer service. If you require air freight delivery to your door, please contact us via email to modify your order:
Delivery Duty Paid Term: The DDP (Delivered Duty Paid) terms apply, which include all fees, unless shipping services are not available in your country. If this situation applies to you, we will reach out to you directly.
